Features

• Low Phase Noise

• Minimal Group Delay

• No Spectral Inversion

• RF-IF Sample Outputs

• High Stability Reference

• Instantaneous Bandwidths

• Local and-or Remote Control

• Low Intermodulation Distortion

• Multiple RF Output Levels Available

• Excellent Phase Noise Characteristics

• Frequency Tuning in 125 KHz or 1 KHz Steps

• Ultra Linearity over Normal Modulation Bandwidth

• Built In Test Capability including Status and Alarms

• Programmable Frequency and Attenuation Settings

• Single, Dual and Multi-Channel Inputs and Outputs available

Downconverter Input Frequencies

• L-Band from 1.4 to 1.7 GHz

• S-Band from 1.7 to 2.4 GHz

• C-Band from 5.8 to 6.5 GHz

• X-Band from 7.2 to 8.5 GHz

• Ku-Band from 13.7 to 14.5 GHz

• K-Band from 21.2 to 23.6 GHz

Upconverter Output Frequencies

• L-Band from 1.4 to 1.7 GHz

• S-Band from 1.7 to 2.4 GHz

• C-Band from 5.8 to 6.5 GHz

• X-Band from 7.2 to 8.5 GHz

• Ku-Band from 13.7 to 14.5 GHz

• K-Band from 21.2 to 23.6 GHz

Upconverter input frequencies are available in the VHF and UHF ranges

Downloads

     DOWNC-6400-8500-70 Downconverter Spec Sheet

      WV-UCV-20-3000-70 - Dual-Band Upconverter

      WV-DCV-4000-70  Downconverter

      WV-DCV-2250-70 Downconverter

      WV-UDCV-2200-2290-70 Up/Down Converter
