• Frequency Range: 2025 to 2120 MHz

• RF Output Power: 25 Watts to 200 Watts

• RF Output Level Adjust:  20dB in 1 dB steps

• RF Input Power: 0 dBm nominal, +2 dB

• Input/Output VSWR: 1.5:1 maximum (Ref 50W )

• Output Protection: No Oscillation, No Damage into infinite VSWR, at
  any Phase Angle (Isolator Protected)

• Noise Figure: 10 dB maximum

• Spurious Outputs: No greater than –60 dBC, except Harmonics, of
  20 dBC maximum

RF Power Options

• 25 Watts

• 50 Watts

• 100 Watts

• 200 Watts

Controls & Reporting

• Interface: RS232, RS422 or RS485

• Control Signals: Output Power Adjust (1dB steps from 1 to 25 watts)

• Reported Signals: Forward and Reflected Power

Power Supply Characteristics

• AC Input Power: 110VAC +10% @ 7 Amperes maximum, 47 to 63 Hz

• DC Output Power: 12 Volts @ 50 Amperes

• Control: Remote AC on via 15 volt 0.20 Ampere signal

• Safety: Door Interlock Switch with Over-Ride and Lamp Indication

• Fuses: 7 Ampere Fuses
